WS-100 3mm Universal Wheel Spacer - 4 & 5 Lug Multi-Fit, 78mm ID, 151mm OD
by C-HORSE
Sold out
$0.00
The WS-100 is a 3mm (1/8") universal wheel spacer that fits a wide range of 4-lug and 5-lug bolt patterns. It slips over the existing wheel studs to add a small amount of clearance between the hub and the wheel, which helps correct minor rub against calipers, hub edges, or suspension components.
Key Features
- 3mm (1/8") thickness for fine clearance adjustment
- Universal slotted design fits both 4-lug and 5-lug bolt patterns
- Fits 4-lug patterns from 98mm to 130mm (3 3/4" to 4 1/2")
- Fits 5-lug patterns from 100mm to 130mm (4" to 5")
- 78mm (3 1/16") center bore (I.D.)
- 151mm (5 15/16") outside diameter (O.D.)
- Uses the vehicle's existing studs and lug nuts, no extra hardware required
Specifications
| Part Number | WS-100 |
| Type | Universal Wheel Spacer (4-Lug & 5-Lug) |
| Thickness | 3mm (1/8") |
| Center Bore (I.D.) | 78mm (3 1/16") |
| Outside Diameter (O.D.) | 151mm (5 15/16") |
| 4-Lug Patterns (Metric) | 4x98, 4x100, 4x108, 4x110, 4x114.3, 4x120, 4x130mm |
| 4-Lug Patterns (Standard) | 4x3 3/4", 4x4", 4x4 1/4", 4x4 1/2" |
| 5-Lug Patterns (Metric) | 5x100, 5x108, 5x112, 5x114.3, 5x115, 5x120, 5x130mm |
| 5-Lug Patterns (Standard) | 5x4", 5x4 1/4", 5x4 1/2", 5x4 3/4", 5x5" |
| Lug Count | 4 or 5 |
Available Pack Sizes
- 1 PCS - single spacer
- 2 PCS - one pair (one axle)
- 4 PCS - full set (front and rear)
Confirm the studs still have adequate thread engagement after installation, check wheel, tire, and fender clearance, and torque the lug nuts to specification.
